VMR-FR30500L
Fast-transit AMR
Ultra-Precise Handling for Lithium Battery Production.
Streamline lithium battery production with the LXSR-CM51500Z coating machine material handling robot. It handles loading/unloading of copper and aluminum foil and core recycling with ±1mm docking accuracy using 3D visual docking and intelligent perception algorithms. Suitable for autonomous and manual charging, it supports a 1600kg load and operates up to 1.0 m/s. The LXSR-CM51500Z enhances precision and efficiency, making it essential for lithium battery manufacturing.
FEATURES
Employs independently developed main control and business modules, offering high integration, stability, and reliability
Highly versatile floating docking platform supports multi-dimensional precise docking requirements, suitable for most application scenarios
Utilizes 3D visual SLAM for autonomous positioning and navigation, complemented by 2D code navigation for precise positioning
Supports multiple autonomous charging methods such as scheduled, fixed-point, and low-power return-to-home.
TECH SPECS
| Dimensions(L*W*H) | 665L*430W*470Hmm |
| Net Weight | 90kg |
| Rotation Diameter | Φ715mm |
| Lifting Height | 400 mm |
| Rated Lifting Load | 50 kg |
| Rated Towing Load | Not Support |
| ※Flexible rotation | Not Support |
| Protective Range | Including the body and the load-carrying rack |
| Protective Measures | Three-level protection: deceleration, gradual stop, emergency stop |
| Laser Obstacle Avoidance | 360° coverage by front & rear laser |
| Safety Edge | All-round protection |
| E-stop Button | The reachable range of a single hand around the body |
| Audio-Visual Alarm | Light indication+ Audio prompt |
| Vision Obstacle Avoidance | Optional |
| Drive Mode | 2 steering wheel drive |
| Navigation Mode | Natural navigation |
| Driving Direction | Forward, backward, rotate, left / right turn |
| Speed | 0~1.5 m/s |
| Navigation Accuracy | ±20 mm |
| Docking Accuracy | ±10 mm (laser docking), ±5 mm (QR code visual docking) |
| Battery Type | LFP |
| Battery Life | ≥8h |
| Charging Method | Automatic / Manual charging |
| Charging Time | ≤1.5h |
| Life Cycle | 1500 cycles |
| LCD Panel | Optional |
| Light Indication | Robot status, fault alarm, battery power, etc. |
| Sound Prompt | Turing, warning, music playback, etc. |
| Button Operation | Emergency stop button, power switch button, operation button |
| Expansion Interface | RJ45(100MB) |
| Application Scenarios | Indoor |
| Operating Temperature | 0~40℃ |
| Humidity | 10~90%RH, no condensation |
